Eaglewood Technologies Sanilox - Anilox Roll Cleaning

Sanilox ™ Anilox Roll Cleaning Systems

Eaglewood Technologies Sanilox ™ Anilox Roll Cleaning Systems for packaging and label printers

Experience counts and Eaglewood Technologies has been the leader in innovative, safe anilox roll cleaning systems for over one quarter century!

Sanilox™ - The Fastest and Most Efficient Anilox Roll Cleaning System on the Market

The Sanilox™ system is an innovative, environmentally-safe anilox roll cleaning system engineered by Eaglewood Technologies. Sanilox™ is easy to operate and is controlled by a simple touch screen interface.

Deep Cleaning

The Sanilox™ system fractures the media to below six microns when applied at 35 psi. This means the media reaches the bottom of the cell, ensuring the entire cell gets cleaned (not just the wall of the cell).

Dust-Free Operation

The Sanilox™ system uses a two-stage HEPA filtering system that delivers dust-free operation throughout the entire cleaning process. There is one collection point for easy disposal and zero mess.

Automation

The touch screen interface allows for information to be easily entered and stored for simple recall.

In-Press and Off-Press Options

The Sanliox™ system can be quickly and easily transformed from an in-press to an off-press system. No other machine on the market today offers this flexibility.

Sanilox™ Advantages:

  • Quick and easy to use
  • One system cleans rolls of any diameter
  • A color touch screen makes it easy to operate and track roll inventory data
  • Increases the life of your rolls
  • One year warranty and 90 day money back guarantee

Sanilox™ Cleans:

  • Any ink, coating, varnish or glue chemistry
  • Journaled rolls
  • Sleeves
  • Gravure rolls
  • Glue rolls
  • Coating rolls
  • Adhesive rolls

Sanilox™ Features & Benefits Video
Sanilox™ Features & Benefits Video

Sanilox™ Off Press Roll Cleaning Video
Sanilox™ Off Press Roll Cleaning Video

Sanilox™ In Press Roll Cleaning Video
Sanilox™ In Press Roll Cleaning Video

Simple Touch Screen Interface

Easy-to-use Touch Screen

How It Works

The Sanilox™ media delivery system fractures the media to below six microns when applied at 35 psi – this means the media reaches the bottom of the cell, ensuring the entire cell gets cleaned (not just the walls of the cell). Other media blasters, including plastic, use a lower pressure in order to “recycle” and re-use media. At a lower pressure, the cleaning time can take up to four times as long. “Recycling” units are less effective cleaning machines since the ink and anything else that is being removed gets recycled as well. This means the roller never truly gets cleaned and dried ink is driven into it over and over.

Flexible Applications

Sanilox™ In-Press

Sanilox System

Cleans anilox rolls in-press by attaching the track via magnets to the print deck.


Sanilox™ Off-Press

Sanilox Cart

Cleans anilox rolls off-press by using the Anilox Roll Cart attachment. The operator can start the system, walk away, and return to a clean roll.

System Specifications

Sanilox™ System

  • Footprint: 63” L x 27” W x 65” H
  • Weight: 985 lbs
  • Air: 80 psi, 3/8” quick connect fitting
  • (2) 110 volt / 20 Amp dedicated electrical outlets

Anilox Roll Cart

  • Footprint: 107” L x 32” W x 41” H
  • Weight: 560 lbs
  • (1) 110 volt electrical outlet
